MAX-4 NIJ Level III/IV (3/4) Hard Armour Plate

MAX-4 NIJ Level III/IV (3/4) Hard Armour Plate
  Zoom
MAX-4 NIJ Level III/IV (3/4) Hard Armour PlateMAX-4 NIJ Level III/IV (3/4) Hard Armour PlateMAX-4 NIJ Level III/IV (3/4) Hard Armour PlateMAX-4 NIJ Level III/IV (3/4) Hard Armour Plate
Size Options:
Protection Options:
Shape Options:

Model:  HAP-MAX4

Availability:

Please contact us to order this item. Or visit our retail website www.vestguard.co.uk




Design Features

NIJ level IV (4) Certified tested to both NIJ level III (3) and IV (4) for peace of mind

Multi-hit protection against 7.62x51mm NATO Ball, 7.62x39mm AK47, 5.56x45mm SS109 and 30.06 API 7.62x63mm 30 Calibre

Drop tested

Water, oil and vibration resistant

Temperature, altitude and pressure stable

Easy wipe clean finish

Protection Level Protection Shape  Size Weight (approx)
NIJ IV 0101.06 ICW (In-Conjunction-With)  Single Curve (shooters cut) 250 x 300 x 15mm  2.8KG
NIJ IV 0101.06 ICW (In-Conjunction-With)  Multi Curve (shooters cut) 250 x 300 x 15mm  2.8KG
NIJ IV 0101.06 ICW (In-Conjunction-With)  Single Curve (shooters cut) 250 x 300 x 18mm  2.35KG
NIJ IV 0101.06 SA (Standalone)  Single Curve (shooters cut) 250 x 300 x 20mm 2.55KG
NIJ IV 0101.06 SA (Standalone)  Multi Curve (shooters cut) 250 x 300 x 20mm 2.60KG
NIJ IV 0101.06 SA (Standalone)  Single Curve (square cut) 150 x 200 x 20mm 1.00KG

Other sizes, models and shapes available upon request

Threat Level Bullet Calibre and Type Image Bullet Mass Impact  Velocity
      (grains) ft/s m/s
NIJ level III (3)      7.62x62mm NATO FMJ (M80 Ball)  148 2780 847
NIJ level IV (4)   .30 calibre AP M2 30.06 166 2880 878

Independent testing to conform with UK and International standards

Ten (10) year HAP guarantee*

Manufactured using high quality materials

CE marked ergonomic tests for extended use

Production ISO9001:2008 quality controlled

Design and style may vary to image shown at VestGuard discretion

Weights quoted are subject to a manufacturing tolerance of +/- 10%



Be the first to Write a Review for this item!

Sizing Guide

Measuring for Body Armour

(Please consider the clothing that will be worn during typical duties in your body armour)

  Chest Waist / Stomach Front length Back Length
  Inches (cm) Inches (cm) Inches (cm) Inches (cm)
Small 34-38 (86-96) 26-30 (66-76) 13 (33) 17 (43)
Medium 38-43 (96-109) 30-34 (74-86) 14 (35) 18 (46)
Large 43-46 (109-116) 34-38 (86-96) 15 (38) 19 (48)
XL 46-48 (116-122) 38-42 (96-107) 16 (40) 20 (51)
XXL 48-50 (122-127) 42-46 (107-117) 16.5 (42) 20.5 (52)
XXXL 50-52 (127-132) 46-50 (117-127) 17 (43) 21 (53)
XXXXL 52-53 (132-135) 50-53 (127-137) 17.5 (44) 21.5 (54)


Measuring for Helmets and Gloves

Helmet – Take measurement from the forehead and extend the tape all the way around your head

Gloves – Using your strongest hand wrap tape between thumb and forefinger and around your whole palm. Make a loose fit

  Minimum Head Circumference Hand Circumference
  Inches (cm) Inches (cm)
Small 52-54 (20.5-21.2) 8 (20.3)
Medium 54-59 (21.2-23.2) 9 (22.9)
Large  57-63 (22.5-24.8) 10 (25.4)
XL 63-64 (24.8-25.2) 11 (27.9)
XXL   12 (30.5)


Downloads

Size Guide (body armour, protective helmets and gloves)

Measurement Sheet (female body armour and helmet)

Measurement Sheet (male body armour and helmet)
